GLUEMAX Spring-Loaded Mini Slide Hammer

Powerful Pulls. Smooth Control.

A compact, spring-loaded slide hammer that puts strong, controlled pulling force in one hand.

The GLUEMAX Spring-Loaded Mini Slide Hammer delivers a smooth sliding action with the pulling force you need for effective dent removal. The spring-loaded design extends the tool from 10.6" to 15" during operation, giving you a consistent, controllable stroke on every pull.

The open-side head slides onto the tab from the side, so you can move from tab to tab without slowing down. It uses the same glue tabs as the GLUEMAX Mini Dent Lifter (DF-GM600SP), so one set of tabs works across your GLUEMAX tools.

Heavy-duty metal construction stands up to daily shop use, and the textured handle gives you a secure, comfortable grip. Use it on its own, or pull lows with it while the GLUEMAX Tension Puller holds lateral tension on the panel.

The GLUEMAX Spring-Loaded Mini Slide Hammer is ideal for:

• Glue pull dent removal on small to medium dents
• Door dings, hail damage, and body line damage
• Pulling lows while a GLUEMAX Tension Puller holds lateral tension
• Areas with limited room for a larger pulling tool

It’s built for collision repair shops, PDR technicians, and mobile repair specialists.

Controlled Pulling Power
A smooth sliding action delivers strong, controlled pulling force for effective dent removal.

Spring-Loaded Sliding Action
The spring-loaded design extends the tool from 10.6" to 15" (27 to 38 cm) during operation, for a consistent, controllable stroke.

Open-Side Head
Slide the tab in from the side for fast tab changes and quick moves across the repair.

Shares GLUEMAX Tabs
It uses the same glue tabs as the GLUEMAX Mini Dent Lifter, so one tab supply covers both tools.

Heavy-Duty Metal Construction
Durable metal construction stands up to daily shop use.

Non-Slip Textured Grip
The textured handle provides a secure, comfortable grip.

Works with the GLUEMAX System
Pull lows while a GLUEMAX Tension Puller holds tension, and blend highs with the Dent Fix Blending Hammer 4 PC Set (DF-BHSET).

(1) GLUEMAX Spring-Loaded Mini Slide Hammer, DF-GMSH.

• Part number: DF-GMSH
• Length in operation: 10.6" to 15" (27 to 38 cm)
• Construction: Heavy-duty metal
• Grip: Textured, non-slip
• Head: Open-side tab slot
• Tab compatibility: Same tabs as the GLUEMAX Mini Dent Lifter (DF-GM600SP)
• Package dimensions: 12.1" x 2.5" x 2.2"

GLUEMAX Mini Slide Hammer Operating Manual (PDF)

1. Prepare the surface. Clean the repair area and tab face with 99% isopropyl alcohol. Glue bonds best on a panel between 75 and 90°F.
2. Glue and place the tab. Seat a glued tab at the center of the low and let it cool to between 75 and 90°F.
3. Pull. Slide the tab fully into the open side of the head, hold the tool in line with the tab, and work the slide with short, controlled strokes. Start light and build up.
4. Release and clean up. Slide the head off the tab, free the tab with isopropyl alcohol, and remove leftover glue.

Always wear safety glasses. See the Operating Manual (PDF) for full instructions.
